AX3000 Wifi 6 Router
AX3000 WIFI 6 Router
Production Introduction
SWR-4GE30W6 is an excellent networking device that is designed to enhance the connectivity experience for users. Its high level of integration has made it smaller and lighter, while also consuming lesser power, making it an eco-friendly choice. This device's flexibility of port usage means that users can use the ports as needed, and it's equipped with four antennas to ensure a stable network connection. The mesh networking technology means that users can enjoy full Wi-Fi coverage and seamless roaming, resulting in a superior network experience. Overall, the SWR-4GE30W6 is an outstanding networking device that is sure to impress users.
SWR-4GE30W6 AX3000 WIFI 6 Router
With its high-performance chipset, this device offers unprecedented gigabit WiFi speeds of up to 3 Gbps and 160Mhz bandwidth. This is made possible by the OFDMA + MU-MIMO technology, which allows for the connection of multiple devices at once without losing speed or connectivity.
The AX3000 Router is highly integrated and offers a sleek, small design for minimalist homes. Despite its compact size and light weight, it packs a punch with its high-performing capabilities. Whether you're working from home, streaming movies or playing games, this router is the perfect upgrade for your network experience.
The device is ideal for those with multiple devices in their household, as it allows for a stable connection regardless of the number of devices on the network. This is made possible by the 160Mhz bandwidth, which means more data can be transferred at once, making for a smoother experience for users.
One of the most impressive features of the AX3000 Router is its OFDMA + MU-MIMO technology. This means that not only is it optimized for current devices, but it will provide the best connectivity experience for any future devices using WiFi 6.
Key Features
High Performance Chipset
Next-Gen Gigabit WiFi Speed up to 3 Gbps,160Mhz bandwidth
Connect More Devices OFDMA + MU-MIMO
Highly integrated
small size and light weight
Details
Patameters
| Hardware Parameter | |
|
Dimension |
179.9mm* 104. 1mm*30.8mm (L*W*H) |
|
Net weight |
185g |
|
Working condition |
Working temp: -30~+60.C Working humidity:5~95%(non-condensing) |
|
Storing condition |
Storing humidity:5 95% (non-condensing) |
|
Power adapter |
DC 12V, 1A |
|
Power supply |
≤12W |
|
Interface |
1GE WAN+3GE LAN + WiFi6 |
|
Indicators |
SYS |
|
Button |
Reset/WPS |
|
Interface Parameter |
|
|
User Interface |
4* 10/ 100/ 1000Mbps auto adaptive Ethernet interface , RJ45 connectors( 1*WAN, 3*LAN) |
|
WLAN Interface |
• Compliant with IEEE802 . 11b/g/n/ac/ax • 2402 Mbps on 5GHz and 574Mbps on 2.4 GHz • 2.4GHz: 2*2(3dBi), 5GHz: 2*2(5dBi);External antennas • Maximum number of connected devices:128 |
| Function Data | |
|
Management |
WEB/Telnet/TR-069/SSH/CLI Management |
|
Multicast |
• Support IGMP Snooping( IGMPv1/v2/v3) • Support IGMP Proxy • Support MLD Snooping(MLDv1 ,MLDv2) • Support MLD Proxy • Support Fast leave |
|
WAN |
Maximum speed of 1Gbps |
|
Wireless |
• Wi-Fi 6: 802. 11a/n/ac/ax 5GHz & 802. 11b/g/n/ax 2.4GHz • WiFi Encryption:WEP-64/WEP-128/ WPA/WPA2/WPA3 • Support MU-MIMO & OFDMA • Support Dynamic QoS • Support 1024-QAM • Support WMM • BSS-Coloring&Beamforming&Beamsteering • Support WIFI Easy-mesh function |
|
L3/L4 |
• Support IPv4, IPv6 and IPv4/ IPv6 dual stack • Support DHCP/PPPOE/Statics • Support Static route,NAT • Support DMZ, ALG,UPnP • Support Virtual Server • Support NTP (Network Time Protocol) • Support DNS Client and DNS Proxy |
|
DHCP |
Support DHCP Server & DHCP Relay |
|
Security |
• Support local access control • Support IP address filtering • Support URL filtering • Support Anti-DDoS attack function • Support Anti-port scanning function • Suppression of protocol-specific broadcast/multicast packets (e.g. DHCP, ARP, IGMP, etc.) • Support Anti-Intranet ARP Attack • Support Parental control function |
Packing& Shipping
Profile
Hangzhou SOFTEL Optic Co., Ltd. is a company specialized in manufacturing telecommunication network products and providing related products integration. We provide the most cost-effective and comprehensive product selection for Fixed and Wireless Broadband Network, 5G, Data Center, ICT and IoT industries that need high-speed information transmission and exchange.
We have more than 100 staff, 10% of them are senior technicians. With more than 1,000 square meters standards production assembling lines, we have strict QC procedures. Each unit of our product will go through 3 layer QC procedures, material checking before production, stabililty and performance testing after production, packing detection before delivery.
Most of our products are exported to South America, Russia, and North European countries. Currently, Softel has its branch office in Mexico and will launch another office in Colombia, continuing supplying for numerous agents, integrated dealers, and equipment producers all over the world.
Through keen international business competition in good faith, all of our staff members feel a big accomplishment & work under heavy responsibility. In addition, we are much proud of providing our invaluable customers with our high quality, high reliability, high efficiency, and competitive products.
Broadcast TV Products and Services
Equipment and software services cover a wide range, covering analog TV systems, digital TV and lPTV, and other fields. lt meets the comprehensive service needs of TV broadcasting in most countries and regions worldwide.
Optical Wired Access Network System and Solution
Deploy HFC/FTTH/FTTO/FTTB solutions by EPON/GPON/XGS-PON/WDM technologies to provide network access, andsignal transmission from the headend to terminals to provide users with Internet, TV, and telephone services.
Fiber Optic Telecommunication Cable Solutions
Whether you're building a new network from scratch or upgrading an existing one, SOFTEL's fiber optic solutions are the perfect fit. Our products includes outdoor fiber optic cables,indoor drop cables,patch cords and pigtails,MTP/MPO,ODF and joint boxes,fusion splicers,otdr and so on.
SOFTEL offers a one-stop solution for businesses seeking fibre optic communication cables. Our team of experts will work with you to identify your unique needs and provide tailored solutions that meet your specific requirements. We offer a wide range of products, including optical fibers, optical connectors, patch cords, and cable assemblies, all of which are designed to provide reliable connectivity, high-speed data transfer, and superior quality.
