Fiber Optic Fusion Splicer Kit
4 motors accurate core alignment
250 times magnification of fiber cores
Fiber Optic Fusion Splicer Kit FSP-06
Characteristics
Small Size, long battery life
4 motors accurate core alignment
250 times magnification of fiber cores
7s fast splicing, 26s intelligent heating
More than 4000 times electrodes discharging
4400mAh Li-battery, 220 cycles splicing and heating
Inductive automatic heater, not heating without fibers
3 in 1 multi-function clamps, new waterproof structure
Apply to bare fibers, drop cables and jumper wires splicing
Item
| Model: | Fiber Optic Fusion Splicer Kit FSP-06 |
Standard Package:
| Main machine *1 |
Fiber Cleaver *1 | |
Electrodes *1 pair | |
Fiber Stripper *1 | |
Drop Cable Stripper *1 | |
Adaptor *1 | |
Manual(CD) *1 | |
Power Cord *1 | |
Carrying Case *1 | |
Strap *1 |
Specifications of Fiber Optic Fusion Splicer Kit
| Applicable fiber | SM(G.652), MM(G.651), DS(G.653), NZDS(G.655), others(including G.657) |
| Diameter of cladding | 80 -150μm |
| Diameter of coating | 160 – 900μm |
| Splice loss | SM:0.02dB, MM:0.01dB, DS:0.04dB, NZDS:0.04dB |
| Return loss | >60db |
| Fiber cleaved length | 10-16mm (coating diameter< 250μm ), 16mm (coating diameter: 250-1000μm ) |
| Splicing program | 40 groups |
| Operate mode | Manual, Automatic |
| Auto-heating | Available |
| Typical splicing time | Seven seconds |
| Tube heating time | 26 seconds for 60mm and 40mm shrinkable sleeves |
| Fiber view magnification | 250X(X or Y view), 125X(X and Y view) |
Viewing method and display | 2 CMOS cameras, 4.3 inch color LCD monitor |
| Storage of splice result | 4000 results |
| Loss evaluation | Available |
| Tension test | 1.8-2.2N |
| Interface | GUI menu interface, easier operation |
| Battery capacity | 4400mAh Li-battery, typical 220 cycles(splice and tube heat) |
| Power supply | Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V |
| Electrode life | More than 4000 ARC discharges, can be replaced conveniently |
| Terminals | USB 2.0 port, for uploading splice results and upgrading software |
| Operating condition | Altitude: 0-5000m, Humidity: 0-95%, Temperature: -10℃~+50℃; Wind speed:max 15m/s |
| Dimension | 200mm(L)x123mm(W)x95mm(H) |
| Weight | 1.6kg (battery is included) |
FAQ
1. What are the payment terms?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is the most convenient for you.
2.How about the Warranty?
There are 12 months for the warranty.
3. How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, UPS and so on. While for the goods of heavy weight and large volume, air or sea shipment will be recommended .
