WiFi 7 ONU
The ONT-VU4736H is a XPON optical terminal access device (BE3600) that is highly integrated with dual-frequency Wi-Fi7. It is the end-product of optical fiber for operator, which supports ultra-bandwidth access through XPON upstream technology, and provides users with basic WIFI functions, routing, VOIP, and gigabit Ethernet functions. The ONT-VU4736H upstream network ports are XPON ports. The downstream user ports include four GE electrical ports, one VOIP port，and BE3600 WiFi7 WLAN port.
Send Inquiry
Product Introduction
Product Description
Product Overview
The ONT-VU4736H is a XPON optical terminal access device (BE3600) that is highly integrated with dual-frequency Wi-Fi7. It is the end-product of optical fiber for operator, which supports ultra-bandwidth access through XPON upstream technology, and provides users with basic WIFI functions, routing, VOIP, and gigabit Ethernet functions. The ONT-VU4736H upstream network ports are XPON ports. The downstream user ports include four GE electrical ports, one VOIP port ,and BE3600 WiFi7 WLAN port.
Specification
|
HardwareSpecifications
|
Description
|
|
Port
|
4GE+1VOIP+1USB+WIFI7+G/EPON
|
|
LED
|
POWER+PON/LOS+INTERNET+LAN+VOIP+WiFi_2.4G+WiFi_5G+WPS+USB
|
|
Button
|
POWER+RST+WIFI+WPS
|
|
Flash&Memory
|
Flash:128MB;Memory:256MB;
|
|
PowerSupply
|
12V/2A
|
|
PowerConsumption
|
≤24W
|
|
EnvironmentStandard |
Operating Temperature:-5~45℃
Storage Temperature:-20~70℃ RelativeHumidity:5%~95%(non-condensing) |
|
EnvironmentFriendly
|
RoHs/CE/CCC
|
|
Weight
|
0.35KG
|
|
Sizeand Weight
|
190mm*135mm*33mm(L*W*H)
|
|
Module type
|
ClassB+, SC/UPC(orSC/APC)
|
|
wavelength
|
UP1310nm,Down1490nm
|
|
TX Opticalpower
|
0.5~5dBm
|
|
RX Optical sensitivity
|
-28dBm
|
|
Transmission distance
|
0~20km
|
|
Transmission rate
|
EPON:Upstream1.25Gbps/Downstream1.25GbpsGPON:Upstream1.25Gbps/Downstream2.5Gbps
|
|
LANInterface type
|
LAN1-LAN4:RJ45(10/100/1000Mbps)
|
|
VOIP
|
RJ11
|
|
USB
|
USB3.0
|
|
WIFI
|
Dual-band WIFI7BE3600(2×2MIMOandMLO(2.4G&5G)
|
