Single Mode Simplex 3.0mm Patch Cord

Description

This single mode simplex 3.0mm patch cord is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch or other telecommunication equipment.

single mode simplex 3.0mm patch cord has thick layer of protection,which is used to connect the optical transmitter, receiver, and the terminal box. This is known as "interconnect-style cabling".

Specification:

Item	Fiber Optic Patch Cord
Mode Type	SM MM
Cable Material	LSZH PVC
Cable Diameter	0.9mm, 2mm or 3mm
Cable Length	1m or customized
Connector Type	SC FC LC ST
Number of Fiber	SX DX
Fiber Type	G652D G657A

Item	Unit	Specification
		SM	MM
		SC/PC SC/UPC SC/APC	SC/PC
Insertion Loss	dB	≤0.20
Max. Insertion Loss	dB	≤0.30
Repeatability	dB	≤0.10
Changeability	dB	≤0.20
Return Loss	dB	45 50 60	/
Operation Temperature	℃	-25 ~ +70
Storage Temperature	℃	-40 ~ +85
Fiber type	um	9/125	50/125; 62.5/125
Core number	/	single or dual fiber
Durability	times	≥1000
Industry Standard	/	Bellcore TA-NWT-001209
