8 Way Indoor CATV Satellite Splitter 5~2500MHz
Two way transmission design
Against spikes and ferrite saturation
Round contact insertion pins
The company provides customers with customized quality Outdoor Modular Optical Node, Ftth Mini Node, 16 In 1 Fixed CATV Modulator with a sincere attitude, considerate service and reasonable prices. We will provide our customers with high performance ratio products and excellent service, as well as rich experience in dealing with problems. After we reach a certain production capacity, we need more advanced product design and a larger sales network. In the company's development process, we always provide customers with good products and technical support, and sound after-sales service.
Indoor RF Splitter is a splitter/divider which divides signal from a feed cable into two and more output signals.
Features
2~8 ways available
Two way transmission design
Against spikes and ferrite saturation
Round contact insertion pins
Zinc alloy die casting shall with nickel plated surface treatment
Surface spray-paint treatment, anti-oxidation and no color fading
Application
Satellite CATV, HFC
Technical Parameter of Indoor RF Splitter
Item | 2 way splitter | 3 way splitter | 3 way splitter | 4 way splitter | 6 way splitter | 8 way splitter |
Insertion Loss | -dB (Max) | |||||
5 MHz - 47 MHz | 3.5 | 3.5/6.9 | 5.8 | 6.9 | 9.3 | 10.3 |
48MHz - 450MHz | 3.9 | 3.9/7.3 | 6.2 | 7.3 | 9.6 | 11.0 |
451 MHz - 750 MHz | 3.9 | 3.9/7.5 | 6.5 | 7.5 | 9.9 | 11.5 |
751 MHz - 1000 MHz | 4.1 | 4.0/8.0 | 7.0 | 8.0 | 11.0 | 12.5 |
Isolation Loss | -dB (Min.) | |||||
5 MHz - 47 MHz | 22 | 25 | 25 | 25 | 25 | 25 |
48MHz - 450MHz | 26 | 24 | 25 | 24 | 24 | 24 |
451 MHz - 750 MHz | 22 | 23 | 24 | 23 | 22 | 22 |
751 MHz - 1000 MHz | 22 | 21 | 22 | 21 | 21 | 21 |
Return Loss (IN/OUT) | -dB (Min.) | |||||
5 MHz - 47 MHz | 20 | 18 | 18 | 18 | 18 | 18 |
48MHz - 450MHz | 22 | 21 | 21 | 20 | 22 | 22 |
451 MHz - 750 MHz | 20 | 21 | 21 | 20 | 20 | 20 |
751 MHz - 1000 MHz | 20 | 18 | 18 | 18 | 18 | 18 |
General Information | ||||||
Impedance | 75 Ohms | |||||
RFI Shielding | - 120 dB | |||||
Intermodulation | better than -45dBmV | |||||
Test Enviroment:Room Temperature: +20℃ | ||||||
Other Requirement: | ||||||
1. Plastic insert to be in white colour. | ||||||
2. Cap of F port to be in clear white colour | ||||||
3. Grounding screw to be 4 x 12 mm in green, 1/4 hex, open flat slot, philips. | ||||||
4. Fixing screw to be 4 x 18 mm in sheet metal, 1/4 hex, open flat slot, Philips. | ||||||
5. Housing to be bright tin plated | ||||||
6.Threads of F-PORT use 3/8"-32 UNEF-2B. | ||||||
7.500mA current passes from In to one of Out ports. | ||||||
We are determined to become the most trusted supplier of 8 Way Indoor CATV Satellite Splitter 5~2500MHz for users, insisting on technological innovation as the driving force, market demand as the guidance, continuous innovation, and improving the economic and social benefits of the enterprise. Our company has strong production capacity, solid production foundation and complete and scientific quality management system. We will develop more practical products, and demand ourselves from the perspective of consumers.
