Adss Optical Cable





Product overview of Adss Optical Cable



Loose tube construction, tubes jelly filled, elements (tubes and fillers when necessary) laid up around non-metallic central strength member, polyester yarns used to bind the cable core, water blocking tape wrapped the cable core, aramid yarns reinforced, 1 ripcord and PE outer sheath.





Fiber & tube color code of Adss Optical Cable



No	1	2	3	4	5	6
Color	Blue	Orange	Green	Brown	Slate	White
No	7	8	9	10	11	12
Color	Red	Black	Yellow	Violet	Pink	Aqua



Product parameters of Adss Optical Cable



SN	Item	Unit	Value
1	No. of fibers	count	24
2	No. of fibers per tube	count	6
3	Cable structure	count	1+6
4	Thickness of outer sheath	mm	Nominal 1.7
5	Cable diameter (±5%)	mm	11.0
6	Cable weight (±10%)	kg/km	88
7	Maximum allowable tension	N	4000
8	Short term crush	N/100mm	1000
9	Span	m	≤100
10	Wind speed	km/h	60~140
11	Ice thickness	mm	0
12	Installation sag	%	≥1.0





Characteristic of Adss Optical Cable

3.1 Min. bending radius for installation

Static:  10 x cable diameter

Dynamic:  20 x cable diameter

3.2 Application temperature range

Operation:  -20℃ ~ +60℃

Installation:  -10℃ ~ +60℃

Storage/transportation:  -20℃ ~ +60℃

3.3 Main mechanical & environmental performance test



Item	Test Method	Acceptance Condition
Tensile Strength IEC 60794-1-2-E1	- Load: Maximum allowable tension - Length of cable: about 50m - Load time: 1min	- Fiber strain £ 0.33% - No fiber break and no sheath damage.
Crush Test IEC 60794-1-2-E3	- Load: Short term crush - Load time: 1min	- Loss change £ 0.1dB@1550nm after test - No fiber break and no sheath damage.





Characteristic of Adss Optical Cable

G652D fiber information

Mode field diameter (1310nm):              9.2mm±0.4mm

Mode field diameter (1550nm):               10.4mm±0.8mm

Cut off wavelength of cabled fiber (lcc):  £1260nm

Attenuation at 1310nm:                          £0.36dB/km

Attenuation at 1550nm:                         £0.22dB/km

Bending loss at 1550nm (100 turns, 30mm radius): £0.05dB

Dispersion in the range 1288 to 1339nm:  £3.5ps/ (nm•km)

Dispersion at 1550nm:                               £18ps/ (nm•km)

Dispersion slope at zero dispersion wavelength:        £0.092ps/ (nm2•km)



Main mechanical & environmental performance test



Item	Test Method	Acceptance Condition
Tensile Strength IEC 794-1-2-E1	- Load: Short term tension - Length of cable: about 50m	- Fiber strain £ 0.15% - Loss change £ 0.1 dB @1550 nm - No fiber break and no sheath damage
Crush Test IEC 60794-1-2-E3	- Load: Short term crush - Load time: 1min	- Loss change £ 0.05dB@1550nm - No fiber break and no sheath damage.
Impact Test IEC 60794-1-2-E4	- Points of impact: 3 - Times of per point: 1 - Impact energy: 5J	- Loss change £ 0.1dB@1550nm - No fiber break and no sheath damage.
Temperature Cycling Test YD/T901-2001-4.4.4.1	- Temperature step: +20oC→-40oC→+70oC →+20oC - Time per each step: 12 hrs - Number of cycle: 2	- Loss change £ 0.05 dB/km@1550 nm - No fiber break and no sheath damage.



Package of Adss Optical Cable





Production process of Adss Optical Cable
