Communication Cmr Cat5e CAT6 Patch Cord Network LAN Cable
We normally follow the tenet of customer-oriented, details-focused for Gpon 8 Ports Optical Line Terminal, Cable TV Optical Node, LC APC UPC Fiber Optic Adapter. The effective operation of our quality system has enabled the company's product quality to be steadily improved. Our company has always adhered to the 'customer first, quality first' principle, Since its establishment, it has established a strict quality management system. Over the years, relying on superb technology and professional services, our company has grown rapidly in the industry.
Cat 5e Lan Cable
| FTP 4Pairs cable- Category 5-PE | |||||
Description | FTP Cat 5e Lan Cable 4P-PE | ||||
Standard | ISO/IEC11801、TIA-568-C.2 、YD/T1019 | ||||
Carton Dimension | ---- | ||||
Cable Packing | Wooden Tray & Carton | ||||
Construction of Cat 5e Lan Cable | |||||
Conductor | Solid-Bare copper |
Insulation colors | Blue,White/Blue | Rip Cord | yes |
Conductor Dia. | 0.50mm±0.005 | Orange,White/Orange | Jacket | PE | |
Insulation | HDPE | Green,White/Green | Jacket Colors | Black | |
Insulation Dia. | 1.0mm±0.03 | Brown,White/Brown | Jacket Out Dia. | 6.2mm±0.4mm | |
Drain wire | 0.45mmTC | Shielded | AL Foil | Average Thickness | 0.55±0.05mm |
Electrical Characteristics | |||||
Frequency(MHz) | ATT (≤dB/100m) | NEXT (≥dB) | ELFEXT (≥dB) | RL (≥dB) | PS NEXT (≥dB) |
1 | 2.0 | 65.3 | 63.8 | 20.0 | 62.3 |
4 | 4.1 | 56.3 | 51.7 | 23.0 | 53.3 |
8 | 5.8 | 51.8 | 45.7 | 24.5 | 48.8 |
10 | 6.5 | 50.3 | 43.8 | 25.0 | 47.3 |
16 | 8.2 | 47.3 | 39.7 | 25.0 | 44.3 |
20 | 9.3 | 45.8 | 37.7 | 25.0 | 42.8 |
25 | 10.4 | 44.3 | 35.8 | 24.3 | 41.3 |
31.25 | 11.7 | 42.9 | 33.9 | 23.6 | 39.9 |
62.5 | 17.0 | 38.4 | 27.8 | 21.5 | 35.4 |
100 | 22.0 | 35.3 | 23.8 | 20.1 | 32.3 |
Impedance(1-100MHz) | 100±15 Ohm | DC Conductor Resistance (Ω/100m) max | 9.5 | ||
Capacitance (nf/100m)max | 5.6 | DC Resistance Unbalance(%) max | 5.0 | ||
| Capacitance unbalance(pf/100m)max | 330 | Insulation Resistance(MΩ/100M)max | 500 | ||
FAQ
1. What are the payment terms?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is the most convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 3~5 working days after the deposit is confirmed. If it is out of stock, the lead time depends.
3. How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, UPS and so on. While for the goods of heavy weight and large volume, air or sea shipment will be recommended .
4. How can I place an order?
(1) Negotiation should be agreed upon the prices and specifications of the products.
(2) Then a proforma invoice will be sent for confirmation.
(3) The deposit can be made according to the proforma invoice.
(4) Manufacturing will be started as soon as the payment is confirmed by our bank.
(5) Goods will be sent out within the agreed delivery deadline. And tracking number will be informed.
5. Can you do OEM for us?
Yes, of cause. If there is a certain quantity, we can do OEM including printing, logo, and customized model etc.
Our mission should be to create imaginative products to prospects with a excellent knowledge for Communication Cmr Cat5e CAT6 Patch Cord Network LAN Cable. We have always pursued the service tenet of honesty and quality. We are dedicated to serving new and old customers and making progress together! Our business philosophy is 'integrity, dedication, pragmatism, and win-win'. We sincerely hope to cooperate and develop together with our customers.
