SFT3542K-8 MPEG2 SD IP Encoder is a professional sdi audio & video Encoder. It has 8 CVBS video input interfaces, 8 pairs of unbalanced audio input interfaces, supporting MPEG-2 video encoding and MPEG 1 Layer 2 audio encoding.
Key Features
24×CVBS video inputs, 24 pairs of unbalanced audio inputs.
Support MPEG-2 Video encoding
Support MPEG1 Layer II, AC3(2.0) Audio encoding and support audio gain adjustment
Support IP(MPTS/SPTS) output (DATA1) over UDP and RTP
Support “Null PKT Filter” function
Support PCR accurate adjusting
Supports PAL and NTSC SD video formats
Real-time effective encoding output bit-rate monitoring
Support PSI/SI editing and inserting
Control via web management, and easy updates via web
Lowest cost per channel, breakthrough price
Specifications of 8 In 1 Sdi Video Encoder
Input | 24 CVBS inputs , RCA interface | ||
Video | Resolution | 720×480_60i, 544×480_60i, 352×480_60i | |
720×576_50i,704×576_50i,640×576_50i, 352×288_50i | |||
Encoding | MPEG-2 | ||
Bit-rate | 0.5Mbps~8Mbps each channel | ||
Rate Control | CBR | ||
GOP Structure | IBBP | ||
Advanced Pretreatment | De-interlacing, noise reduction | ||
Audio | Encoding | MPEG-1 Layer 2, AC3(2.0) | |
Sampling rate | 48KHz | ||
Resolution | 24-bit | ||
Bit-rate | 128Kbps,192kbps,256kbps,320kbps,384kbps each channel | ||
Multiplexing | Maximum PID | 180 input per channel | |
Function | PID remapping ( automatically or manually) | ||
Accurate PCR adjusting | |||
Generate PSI/ SI table automatically | |||
Stream output | RF output (F type interface) | ||
IP (MPTS/SPTS) output over UDP/RTP, DATA1(GE port) | |||
System function | Network management(WEB) | ||
Chinese and English language | |||
Ethernet software upgrade | |||
Miscellaneous | Dimension(W×L×H) | 482mm×410mm×44mm | |
Approx weight | 8kg | ||
Environment | 0~45℃(work)；-20~80℃（Storage） | ||
Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | ||
Power consumption | 20W | ||
