Gpon 8 ports Optical Line Terminal
Gpon 8 ports Optical Line Terminal is a small-capacity cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirements on account of its excellent management, maintenance, and monitoring capability, abundant service features, and flexible network mode.OLT-G4/OLT-G8 can be used with the NGBNVIEW network management system so as to provide users with comprehensive access and a perfect solution. OLT-G4/OLT-G8 provides 8/16 * downlink GPON port, 4 *GE combo port, and 2* 10G SFP+ port. The height is only 1U for easy installation and space-saving. OLT-G4/OLT-G8 is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.
Product specification
Item | OLT-G4 | OLT-G8 |
Switching Capacity | 63Gbps | 78Gbps |
Forwarding Capacity(Ipv4/Ipv6) | 50.592Mpps | 65.472Mpps |
Service Port | 4*PON port, 4*GE COMBO port, 2*10GE SFP+ port | 8*PON port, 4*GE COMBO port, 2*10GE SFP+ port |
Redundancy Design | Dual power supply Support double AC input, double DC input and AC+DC input | |
Power Supply | AC: input 90～264V 47/63Hz; DC: input -36V～-72V; | |
Power Consumption | 50W | |
Dimensions (Width x Depth x Height) | 437mm×44mm×280mm | |
Weight (Full-Loaded) | ≤5KG | |
Environmental Requirements | Working temperature: -10°C～55°C Storage temperature: -40°C～70°C Relative humidity: 10%～90%, non-condensing | |
Features
Item |
| OLT-G4/OLT-G8-04P/08P |
PON Features
| ITU-TG.984.x; SN/Password/SN+Password/LOID/LOIDPassword/LOID+LOID Passwordauthentication modes; Terminal access up to 60km on a single fiber; 1:64 split ratio on single PON port, scalable to 1: 128 split ratio; DBA algorithm, and the particle is for 64Kbit/s; Standard OMCI management function; ONU batch software upgrade; PON port optical parameter detection; | |
L2 Features | MAC | MAC Black Hole; Port MAC Limit; 32K MAC (packet exchange chip cache 2MB ); |
VLAN | 4K VLAN entries; Port-based VLAN classification; Uplink static QinQ and flexible QinQ(Stack VLAN); Uplink VLAN Swap and VLAN Remark; GVRP; | |
Spanning Tree | STP/RSTP/MSTP; Remote loop detecting; | |
Port | Bi-directional bandwidth control; Support static and LACP dynamic port aggregation; Port mirroring; | |
Security Features | User’s Security | Anti-ARP-spoofing; Anti-ARP-flooding; IP Source Guard for creating IP+VLAN+MAC+Port binding; Port Isolation; MAC address binding to the port and MAC address filtering; IEEE 802.1x and AAA/Radius authentication; |
Device Security | Support the control layer to prevent a variety of DOS attacks and virus attacks against the CPU; SSHv2 Secure Shell; SNMP v3 encrypted management; Login Security IP via Telnet; Hierarchical management and password protection of users; | |
Network Security | User-based MAC and ARP traffic examination; Restrict ARP traffic of each user and force-out user with abnormal ARP traffic; Dynamic ARP table-based binding; IP+VLAN+MAC+Port binding; L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet; Port-based broadcast/multicast suppression and auto-shutdown risk port; URPF to prevent IP address counterfeit and attack; DHCP Option82 and PPPoE+ upload user’s physical location Plaintext authentication of OSPF, RIPv2 and BGPv4 packets and MD5cryptograph authentication; | |
Service Features | ACL | Standard and extended ACL; Time Range ACL; Flow classification and flow definition based on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination IP(IPv4/IPv6) address, TCP/UDP port number, protocol type, etc; packet filtration of L2～L7 deep to 80 bytes of IP packet head; |
QoS | Rate-limit to packet sending/receiving speed of port or self-defined flow and provide general flow monitor and two-speed tri-color monitor of self-defined flow; CAR(Committed Access Rate),Traffic Shaping and flow statistics; Packet mirror and redirection of interface and self-defined flow; Supports priority marking of ports or custom flows and provides 802.1p, DSCP-priority Remark capability; Super queue scheduler based on port or self-defined flow. Each port/flow supports 8 priority queues and scheduler of SP, WRR andSP+WRR; Congestion Avoidance Mechanism, including Tail-Drop and WRED; | |
IPv4 | ARP Proxy; DHCP Relay; DHCP Server; Static Routing; RIPv1/v2; OSPFv2/V3; Equal-cost multi-path routing; Policy-based routing; Routing policy | |
IPv6 | ICMPv6; ICMPv6 Redirection; DHCPv6; ACLv6; IPv6 and IPv4 dual stack; | |
Multicast | IGMPv1/v2/v3; IGMPv1/v2/v3 Snooping; IGMP Filter; MVR and cross VLAN multicast copy; IGMP Fast leave; IGMP Proxy; PIM-SM/PIM-DM/PIM-SSM; MLDv2/MLDv2 Snooping; | |
Reliability | Loop Protection | ERRP or ERPS; Loopback-detection; |
Link Protection | FlexLink (recover-time <50ms); RSTP/MSTP (recover-time <1s); LACP (recover-time <10ms); BFD; | |
Device Protection | VRRP host backup; 1+1 power hot backup; | |
Maintenance | Network Maintenance | Port real-time, utilization and transmit/receive statistic RFC3176 sFlow analysis; LLDP; GPON OMCI; Data Logging and RFC 3164 BSD syslog Protocol; Ping and Traceroute; |
Device Management | Console port, Telnet, SSH management; Out-band management; SNMPv1/v2/v3; RMON (Remote Monitoring)1,2,3,9 groups MIB; SNTP; NGBNView network management; Power Failure Alarm; | |
Characteristics
1, Meet ITU-T G.984/G.988 standard and relative GPON standards of Chinese Communication Industry
2, Support OMCI remote management for ONT/ONU, compatible with ITU-T G.984.4/G.988 OMCI Protocol
3, 1U height 8PON OLT product in compact design of Pizza-Box
Layer 2 Switching Function OLT equips with very powerful layer 2 Full Wire Speed Switching and completely supports layer 2 protocol. OLT supports varieties of layer 2 functions like TRUNK, VLAN, LACP, rate limit, port isolate, queue technology, flow control technology, ACL and so on, which provides technical guarantee for the development of multi-service integrated.
4, QOS Guarantee GPON Products maintains fully-improved DBA with excellent Qos service capabilities. DBA meets different Qos requirements from different service flow in latency, jitter, packet loss rate.
5, Easy-to-Use Management SystemGPON OLT OLT-G8 Support management method of CLI, SNMP, TELNET, SSH and meet OMCI standard, through OMCI channel protocol service management can be realized, including ONT function parameter set, T-CONT business lines and amount, Qos parameters, configuration information request, performance statistics, auto-reporting of running events in system, configuration for ONT from OLT, fault diagnosis and management of performance and safety.
