64 Port EDFA with Big Screen
Our company shows the business integrity and social responsibility of the enterprise with the continuous improvement of Fiber Optic Termination Box, High Performance OTDR, MXQPRO Android Tv Box quality and considerate pre-sale, in-sales and after-sales services. Our company has accumulated full experience and professional international service knowledge in the international market for a long time. Our products will continue to improve inside the order and appear forward to cooperation with you, Definitely should any of those goods be of curiosity to you, be sure to letus know. In order to meet the needs of modern high-tech, we actively introduce talents so as to gradually form a reasonable talent echelon. We adhere to the company tenet of 'excellent quality, complete variety, preferential prices, and timely delivery' to provide customers with better service and product quality.
Mini EDFA
Features
Select internationally renowned brands oflow noise pump lasers.
Mini EDFA has low distortion, wide band, high output optical.
Built-in lithium battery,to ensure equiptment can go on work after power.
Product Paramenters of Mini EDFA
| Item | Technical Parameter | Note |
| Bandwidth | 1535~1565nm | |
| Input Power Range | -5dBm~ +10dBm | Nominal input + 3 dBm |
| Output Power Range | （13~14）dBm | |
| Output Power Stability | ±0.1dBm | |
| Noise Figure | ≤5.0dB | @+0dBm input，λ=1550nm |
Return | Input | ≥45dB |
| Output | ≥45dB | |
| Optical Connector Type | SC/APC（Standard）& FC/APC | Customizable |
| C/N | ≥50dB | Test condition：GT/T 184-2002 |
| C/CTB | ≥63dB | |
| C/CSO | ≥63dB | |
| Power Supply | DC 9V | External power supply |
| Power consumption | ≤10W | |
| Operating Temperature | -5~+42℃ | |
| Storage Temperature Range | -30~+70℃ | |
| Humidity | 95%（non-condensing） | |
| Size | 310(L)*243(W)*81(H)mm | |
| Weight（with packing box） | 1.2Kg | Equipment & Power Supply |
It is the countless 'Never Give Up' that allows our Fullwell 64 Port EDFA with Big Screen to achieve a place in the market. At present, we are committed to integration, creating value, accelerating team building, opening up and achieving win-win results. We have always adhered to integrity, excellence and long-term planning.
