High Gain Universal Ku Band LNB
47-862MHZ & 950-2600MHZ
WDM is optional
Our company is willing to produce high-quality, high-value-added Satellite LNB Mutiswitch, Trunk Cable Stripper Coring And Striping Tool, CATV Modulator 16 Channel for users in a down-to-earth manner with the philosophy of 'honesty and trustworthiness, mutual benefit and win-win, technological progress, and common development'. We provide a two-tiered development path of technology and management for employees' career planning to maximize personal value. We emphasize the introduction of key talents, making good use of existing talents, and cultivating future talents.
Satellite Receiver For TV
Satellite Receiver for TV SOR-201 is 47-862MHZ & 950-2600MHZ; Input Power: -13~0 dBm; Wavelength: 1310nm/1550nm.
Features
With high sensitivity optical detector.
It is an embodiment of high-tech in CATV and L-band satellite fiber linking products
It can be received in an optical fiber with 47～2600MHz satellite and catv digital and analog signals.
Simple installation; It is convenient for user to install.
Input power from +0～-13dBm.
It has a good electromagnetic interference resistance ability.
High performance but low price.
Parameters
Optical Satellite Receiver For TV | |
Working Wavelength（nm） | 1290~1600 |
Input range（dBm） | -13~0 |
Optical Return Loss（dB） | ≥45 |
Fiber Connector | SC/APC |
RF | |
Frequency（MHz） | 47～862 |
Unflatness（dB） | ±1.5 |
Output Level（dBuV） | 66~86@0dBm |
Manual Gain Range（dB） | 0～20±1 |
Output Return Loss（dB） | ≥16 |
Output Impedance（Ω） | 75 |
No. of output port | 2 |
RF connector | F-5(Imperial) |
Link | |
CTB（dB） | ≥62@0dBm |
CSO（dB） | ≥63@0dBm |
CNR（dB） | ≥50@0dBm |
Test Condition： 60(PAL-D)channels, Optical input=0dBm, 3 steps EDFA Noise figure =5dB, distance 65Km, OMI 3.5%。 | |
SAT-IF | |
Frequency（MHz） | 950~2600 |
Output（dBm） | -50~-30 |
Unflatness（dB） | ±1.5dB |
IMD | -40dBc |
Output Impedance（Ω） | 75 |
General | |
Power supply（V） | 12 DC |
Power Consumption（W） | ≤4 |
Working Temp（℃） | 0 ～ 50 |
Storage Temp | -20～85℃ |
Humidity | 20 ～ 85% |
Warranty TermS
SOR-201 Satellite Receiver for TV is covered by one YEAR Limited Warranty, which starts from the initial date of your purchase. We provide its customer whole-life technical supports. If warranty is expired, repair service only charges parts (if required).
We provide customers with perfect products and high-quality services, and strive to create value for customers, and become the best partner for users of High Gain Universal Ku Band LNB! Respect customers, understand customers, and create value for customers is our service tenet. Our advantage lies in our design, production, and sales capabilities, and diverse technologies, which will certainly meet your needs.
