Network Cable Cat 6
Application:
Network Cable Cat 6 provides universal connectivity for wiring your home or office for high-speed network
Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power plant, householdelectrical applance,insurment and telecommunication equipment.
Specifications of Network Cable Cat 6
| U/UTP 4Pairs Cable Category 5E | |||||
Category | U/UTP CAT5E-4P-PVC | ||||
Standard | ISO/IEC11801、TIA-568-C.2 、YD/T1019 | ||||
Carton Dimension | 40.5*40.5*21CM | ||||
Cable Packing | Wooden Tray & Carton | ||||
Construction | |||||
Conductor | Solid-Bare copper |
Insulation colors | Blue,White/Blue | Rip Cord | yes |
Conductor Dia. | 0.50mm±0.005 | Orange,White/Orange | Jacket | PVC | |
Insulation | HDPE | Green,White/Green | Jacket Colors | According to requires | |
Insulation Dia. | 1.02±0.03mm | Brown,White/Brown | Jacket Out Dia. | 6.3±0.4mm | |
Drain wire | NO | Shielded | NO | Average Thickness | 0.55±0.05mm |
| Seperator | Yes | ||||
Electrical Characteristics | |||||
Frequency(MHz) | ATT (≤dB/100m) | NEXT (≥dB) | ELFEXT (≥dB) | RL (≥dB) | PS NEXT (≥dB) |
1 | 2.03 | 74.3 | 67.8 | 20.0 | 64.8 |
4 | 3.78 | 65.3 | 55.8 | 23.0 | 52.8 |
8 | 5.32 | 60.8 | 49.7 | 24.5 | 46.7 |
10 | 5.95 | 59.3 | 47.8 | 25.0 | 44.8 |
16 | 7.55 | 56.2 | 43.7 | 25.0 | 40.7 |
20 | 8.47 | 54.8 | 41.8 | 25.0 | 38.8 |
25 | 9.51 | 53.3 | 39.8 | 24.3 | 36.8 |
31.25 | 10.67 | 51.9 | 37.9 | 23.6 | 34.9 |
62.5 | 15.38 | 47.7 | 31.9 | 21.5 | 28.9 |
100 | 19.80 | 44.3 | 27.8 | 20.1 | 24.8 |
| 200 | 29.89 | 39.8 | 21.8 | 18.0 | 18.8 |
| 250 | 32.85 | 38.3 | 19.8 | 17.3 | 16.8 |
Impedance(1-100MHz) | 100±15 Ohm | DC Conductor Resistance (Ω/100m) max | 9.5 | ||
Delay Shew ns/100m (1-100MHz) | ≤45 | DC Resistance Unbalance(%) max | 5.0 | ||
Capacitance(nF/100m) max | 5.6 | NVP | 69% | ||
