FTTH Optical Receiver WDM
SR201W is a ftth optical receiver WDM with a build-in WDM and is design for FTTH transmission applications. This mini indoor optical receiver is of low noise, high RF output and low power consumption. It is single mode fiber-pigtailed and available with various connector options.
No | Interface | Description |
1 | RF OUT | RF OUT1 F connector |
2 | RF OUT2 optional | |
3 | PWR | Power adaptor port |
4 | PON | 1490/1310mn data interface SC/PC(SC/APC) |
5 | Optical Input | 1550/1490/1310mn Optical input SC/APC |
Features
1. The operating bandwidth is 1 GHz.
2. Input optical range is +2 to -18dBm.
3. The Output level is up to 76dBuV.
4.. RF Output is optional
5. The power consumption is lower than 1.0W.
Specifications of Ftth Optical Receiver Wdm
Item | Parameter | Unit | Notes | |
Optical Specifications (Forward Path) | ||||
Wavelength | 1550/1490/1310 | nm | Com port | |
1490/1310 | nm | For ONT | ||
Power Input Range | -18～+2 | dBm | ||
AGC Range | 0～-12 | dBm | ||
Input Return Loss | ≥45 | dB | ||
RF Specifications (Forward Path) | ||||
Bandwidth | 47～1003 | MHz | ||
Flatness | ±1.0 | dB | 47～1003MHz，At 25 ℃ | |
Slope | 0~2.0 | dB | 47～1003MHz，At 25 ℃ | |
Temperature Stability | ±1.5 | dB | In the operating temperature range (-25 ~ +65 ℃) | |
Output Level | 75±2 | dBuV | -15dBm input optical power, The analog channel, per channel modulation 4.0%, in the 860MHz point test, at 25℃ | |
Impedance | 75 | Ohm | ||
Return Loss | ≥12 | dB | At 25 ℃ | |
MER | ≥30 | dB | -15~-5dBm input optical power | |
≥24 | dB | -20~-16, input optical power | ||
Power | < 1.0 | W | ||
Environmental Parameters | ||||
Working Temperature | -25～65 | ℃ | ||
Storage Temperature | -40～70 | ℃ | ||
Storage Humidity | ≤95 | ％ | Non- condensation | |
User Interface | ||||
Connector Type | SC/APC in | SC Optional | ||
Power supply | DC5V/0.5A | External adapter | ||
RF Output | RG6 Connector | Optional | ||
1 or 2 ports | ||||
Optical Indicator | Shine Red or | Red: Optical power <-16dBm | ||
Housing | 90*85*25 | mm | ||
Weight | 0.15 | kg | ||
