Sxg402 4 Ports Output CATV Trunk Amplifier with Return Path and AGC
Our company strictly follows the quality management system, so that the quality of all our 220V Ftth Catv Optical Receiver, 4 Port Onu Wifi Catv, Dual Mode XPON ONT can be effectively controlled and ensured in the first process. We are based on a high starting point, large investment, high-level operations, adhere to high standards, zero defects, and refinement, seize every development link, and strive to build a 'rest assured' brand. Our company firmly believes that the trust of customers is the greatest affirmation of the company. Only by making customers grow, can the company thrive.
SA1200 outdoor bidirectional AGC trunk amplifier is a new high gain amplifier. It adopts mature and optimized circuit design, scientific and rational internal process, high quality materials, and built-in high performance AGC control circuit, which ensures the stable gain and low distortion. This CATV trunk amplifier with return path is the first choice equipment for large and medium-sized CATV bidirectional transmission network.
Performance Characteristics
■It is more convenient to debug because of the plug-in duplex filter, fixed equalizer and attenuator, plug-in output tap, and the scientific and reasonable on-line detection ports.
■Built-in optimal designed high performance AGC control circuit, make the control more precise and the signal operation more stable.
■CATV trunk amplifier with return path can long time continuous work steadily under outdoor bad environmental condition, because of the aluminum waterproof housing, high reliability switching power supply and strict lightning protection system.
Technique Parameters of CATV Trunk Amplifier With Return Path
Item | Unit | Technical Parameter | ||||
Forward Path | ||||||
Frequency range | MHz | 47/85 ~860/1003 | ||||
Rated gain (@FZ110) | dB | 30 | 34 | 36 | 38 | |
Min full gain (@FZ110) | dB | ≥30 | ≥34 | ≥36 | ≥38 | |
Rated Input Level | dBμV | 72 | ||||
Rated Output Level | dBμV | 106/108 | ||||
Flatness In Band | dB | ±0.75 | ||||
Noise Figure | dB | ≤ 10 | ||||
Return Loss | dB | ≥ 16 | ||||
ATT | dB | 1-18 (Fixed, 1dB stepping, selectable) | ||||
EQ | dB | 1-15 (Fixed, 1dB stepping, selectable) | ||||
C/CTB | dB | ≥67 | Test condition: 79 channels. | |||
C/CSO | dB | ≥69 | ||||
AGC Pilot Frequency | MHz | 168.25 (Or specified by the user) | ||||
AGC Characteristic | dB | ±4 (input) /±0.5 (output) | ||||
Group Delay | ns | ≤ 10 (112.25 MHz/116.68 MHz) | ||||
Signal to Hum Ratio | % | < 2 | ||||
Gain Stability | dB | -1.0 ~ +1.0 | ||||
Return Path | ||||||
Frequency Range | MHz | 5 ~ 42/65 | ||||
Rated Gain (@FZ110) | dB | 12 | 16 | 20 | 24 | |
Max Output Level | dBμV | ≥ 110 | ||||
Flatness In Band | dB | ±0.75 | ||||
Noise Figure | dB | ≤ 12 | ||||
Return Loss | dB | ≥ 16 | ||||
Carrier to Second Order Inter-modulation Ratio | dB | ≥ 52 | Test condition: output level 110dBμV, | |||
Group Delay | ns | ≤ 20 (57MHz/59MHz) | ||||
Signal to Hum Ratio | % | < 2 | ||||
General Characteristic | ||||||
Characteristic Impedance | Ω | 75 | ||||
Test Port | dB | -20±1 | ||||
Power Voltage | V | A：AC（135 ~ 250）V；B：AC（35 ~ 90）V | ||||
Impulse Withstand Voltage (10/700μs) | kV | > 5 | ||||
Power Consumption | W | 22 | ||||
Dimension | mm | 260（L）╳ 200（W）╳ 130（H） | ||||
Package
We specialize in Sxg402 4 Ports Output CATV Trunk Amplifier with Return Path and AGC production and have many years of experience in sales and service of related products so that we can serve customers well and respond quickly to customer needs. Our company has always adhered to the enterprise spirit of 'high quality and efficiency, customer first, striving for priority', and has established a wide range of friendly partnerships with our customers. Casting a century-old brand is our driving force, which is the dream and belief of all employees, and we will play hard for it and never stop.
