4 Port POE ONU

4 Port POE ONU

ONT-4GE-PD dual-mode ONU is one of the XPON optical network unit design to meet the requirement of the broadband access network.



4 Port POE ONU supports EPON and GPON two modes access. The ONU automatically switches into the corresponding PON mode by identifying the local OLT mode to complete GPON or EPON adaptive access.



4 Port POE ONU have a high reliability and provide quality of service guarantee, easy management, flexible expansion and networking. It fully meets the ITU-T technical standards and have good compatibility with third party OLT.



Functional Feature

In compliant with ITU - T G.984 ,IEEE802.3ah Standard

Support POE supply power(PD)

Support POE switch power supply

Support port VLAN configuration

Support mac-address learning

Support port flow-control

Support port-based rate limitation and bandwidth control

Support broadcasting storm resistance function

Support igmp transparent/snooping/proxy mode

Support remote management configuration

EMS network management based on SNMP ,convenient for maintenance

Support power-off alarm function ,easy for link problem detection



Hardware
GPON/EPON Port Single mode single fiber GPON：FSAN G.984.2 standard EPON：1000BASE-PX20+ symmetric GPON：2.488Gbps/1.244Gbps downstream/upstream EPON：1.25Gbps downstream/upstream   Environmental Specifications Operating temperature: -20 to 55ºC Storage temperature: -40 to 85ºC Operating humidity: 10% to 90%(Non-condensing)	User Port(LAN) RJ-45 connector 4* 10/100/1000Mbps adaptive Ethernet port Indicators PWR / PON / LOS / LAN / POE Power Power consumption: <5W Support POE supply power(PD) PD input Voltage: 36~57V DC Dimension and Weight 150mm(L) x 115mm(W) x 30mm (H) 0.5kg

Software



Management EPON :OAM / WEB / Telnet GPON:OMCI / WEB / Telnet Register Auto-discovery/Link detection/Remote upgrade software Auto/MAC/SN/LOID+Password authentication Switch MAC address learning MAC address learning account limit Broadcast storm suppression

Multicast IGMP V2 IGMP VLAN IGMP transparent/Snooping/Proxy Security Firewall MAC address/URL filter Remote WEB/Telnet access control
