Name: China ONT XPON Dual Band Manufacturers, Suppliers - Factory Direct Wholesale - Softel
Brand: Softel
SKU: 248472337

ONT-4GE-RFDW is an amazing device designed for multi-service integration network applications. As an optical network unit device, it offers FTTH/O scenario services to users. This device boasts of four 10/100/1000Mbps ports, a WiFi (2.4G+5G) port, and an RF interface. This configuration enables it to deliver high-speed data services and high-quality video services with ease.

Send Inquiry

Product Introduction

4GE ONT XPON Dual Band WIFI 2.4/5G

Users no longer need to worry about slow internet speeds or poor quality videos because the ONT-4GE-RFDW has got them covered. It ensures users enjoy seamless connectivity and video streaming experience. The device is perfect for both residential and commercial applications, meeting the requirements of different users.

Furthermore, the ONT-4GE-RFDW is easy to install, configure and manage, it offers users a hassle-free experience. It is an excellent tool that simplifies the provision of internet and video services to users. With this device, service providers can deliver reliable, fast, and affordable internet and video services to their customers.

ONT-4GE-RFDW-2

1.Technical Specifications

Hardware parameters

Dimension	220mm x 150mm x 32mm(Without antenna)
Weight	Approximately 310g
Working environment temperature	0℃～+40℃
Working environment humidity	5% RH～95% RH, non-condensing
Power adapter input level	90V～270V AC,50/60Hz
Device power supply	11V～14V DC,1 A
Static power consumption	7.5 W
Maximum power consumption	18 W
Interfaces	1RF+4GE+Wi-Fi(2.4G+5G)
indicator light	POWER/PON/LOS/LAN/WLAN/RF

Interface parameters

PON interface	Class B+ -27dBm receiver sensitivity Wavelength: Upstream 1310nm; Downstream 1490nm Support WBF Flexible mapping between GEM Port and TCONT Authentication method:SN/password/LOID(GPON) Two-way FEC(Forward error correction) Support DBA for SR and NSR
Ethernet port	Stripping based on VLAN Tag/Tag for Ethernet port. 1:1VLAN/N:1VLAN/VLAN Pass-through QinQ VLAN MAC address limit MAC address learning
WLAN	IEEE 802.11b/g/n 2×2MIMO Antenna gain: 5dBi WMM(Wi-Fi multimedia) Multiple SSID multiple WPS
RF interface	Supports standard RF interfaces Support hd data streaming

5G Parameters

Network standard	IEEE 802.11ac
Antennas	2T2R, support MU-MIMO
Maximum supported rates	20M:173.3Mbps 40M:400Mps 80M:866.7Mbps
Data modulation type	BPSK QPSK 16QAM 64QAM 256QAM
Maximum output power	≤20dBm
Typical channel (Customized)	36,40,44,48,52,56,60,64,100,104, 108,112,116,120 ,124,128,132,136, 140,144,149,153,157,161,165
Encryption mode	WPA,WPA2,WPA/WPA2,WEP,NONE
Encryption type	AES,TKIP
