ONT-R4630H XPON HGU 4GE + CATV + WIFI6 AX3000 (2.4G +5G)







ONT-R4630H is launched to be oriented to multi-service integration network as an optical network unit device, which belongs to XPON HGU terminal for FTTH/O scenario. It configures four 10/100/1000Mbps ports, WiFi6 AX3000 (2.4G+5G) port and RF interface that providing with high-speed data services and high-quality video services to users.



Picture of AX3000 Wifi 6 ONT

Highlights: --------------------------------------

Support docking compatibility with OLT of various manufacturers

Support automatically adapt to the EPON or GPON mode used by the peer OLT

Support 2.4 and 5G Hz dual band WIFI

Support multiple WIFI SSID

Support EasyMesh WIFI function

Support WIFI WPS function

Support multiple wan configuration

Support WAN PPPoE/DHCP/Static IP/Bridge mode.

Support CATV video service

Support fast transmission of hardware NAT

Support OFDMA, MU-MIMO,1024-QAM





Features: --------------------------------------

Compliance with IEEE 802.3ah(EPON) & ITU-T

G.984.x(GPON) standard

Compliance with IEEE802.11b/g/n/ac/ax 2.4G & 5G

WIFI standard

Support IPV4 & IPV6 Management and

transmission

Support TR-069 remote configuration and

maintenance

Support Layer 3 gateway with hardware NAT

Support Multiple WAN with Route/Bridge mode

Support Layer 2 802.1Q VLAN, 802.1P QoS,

ACL etc

Support IGMP V2 and MLD proxy/ snooping

Support DDNS, ALG, DMZ, Firewall and

UPNP service

Support CATV interface for video service

Support bi-directional FEC





Application Chart



Hardware Specifications:---------------

interface: 1* G/EPON+4*GE+2.4G/5G

WLAN+1*RF

Power adapter input: 100V-240V AC, 50Hz-60Hz

Power Supply: DC 12V/1.5A

Indicator light: POWER/PON/LOS/LAN1/ LAN2

LAN3/LAN4/WIFI/WPS/OPT/RF

Button: Power switch Button, Reset Button,

WLAN Button, WPS Button

Power Consumption: <18W

Working temperature: -20℃～+55℃

Environment humidity: 5% ~ 95%

(non-condensing)

Dimension：180mm x 133mm x 28mm

(L×W×H Without antenna)

Net Weight：0.41Kg



PON Interface: ---------------------------------

Interface Type: SC/APC, CLASS B+

Transmission distance: 0～20km

Working wavelength: Up 1310nm;

Down 1490nm;CATV 1550nm

RX Optical power sensitivity: -27dBm

Transmission rate:

GPON: Up 1.244Gbps;Down 2.488Gbps

EPON: Up 1.244Gbps;Down 1.244Gbps



Ethernet Interface : ----------------------

Interface type：4* RJ45

Interface parameters：10/100/1000BASE-T





Wireless: ------------------------------------

Interface type：External 4*2T2R External antenna

Antenna gain: 5dBi

Interface maximum rate:

2.4G WLAN： 574Mbps

5G WLAN： 2402Mbps

Interface working mode:

2.4G WLAN：802.11 b/g/n/ax

5G WLAN：802.11 a/n/ac/ax



CATV Interface: ---------------------------

Interface type: 1*RF

Optical receiving wavelength: 1550nm

RF output level : 80±1.5dBuV

Input optical power: 0~-15dBm

AGC range: 0~-12dBm

Optical reflection loss： >14

MER: >35@-15dBm
