Product Introduction

HDMI to ISDB-T encoder modulator

SFT3536S is a professional high integration device which includes encoding, multiplexing, and modulation. It supports 8/16/24 HDMI inputs. It also supports DVB-C RF out, DVB-T/ATSC RF out or ISDB-T RF out.

HDMI encoder modulator

This HDMI to ISDB-T encoder modulator supports 8/16/24 HDMI inputs, 1 ASI input, 1 USB payer input and 128 IP inputs via the GE port. It also supports DVB-C RF out, DVB-T/ATSC RF out or ISDB-T RF out as well as 12/8/6/16 MPTS as mirror of 12/8/6/16 carriers through the GE port and 1 ASI out as mirror of one of the carriers. This full function device makes it ideal for small CATV headend system. And it is a very smart choice for hotel TV system, entertainment system in sports bar, hospital and apartment etc.

Key Features

8/16/24 HDMI inputs, MPEG-4 AVC/H.264 Video encoding

1 ASI input for re-mux

1 USB Player (Insert the USB Flash drive with “xxx.ts” videos in SFT3536S and play back the content in an easy way; file system FAT 32. )

128 IP input over UDP and RTP via GE port

Each carrier out channel processes maximum 32 IP inputs from the GE port(UDP&RTP protocol)

MPEG1 Layer II, LC-AAC and HE-AAC Audio encoding, AC3 Pass Through and audio gain adjustment

Support 8 groups multiplexing/DVB-T modulating

Support 1 ASI out as mirror of one of RF output carriers for option

Support 8 MPTS IP output over UDP, RTP/RTSP

Support LOGO, Caption and QR code insertion

Support PID remapping/ accurate PCR adjusting/PSI/SI editing and inserting

Control via web management, and easy updates via web

Specifications

Input	8/16/24 HDMI inputs for option 1 ASI in for re-mux 1 USB Player input for re-mux 128 IP input over UDP and RTP, GE port, RJ45—DVB-C RF out 128 IP input over UDP and RTP, GE port, RJ45—DVB-T/ATSC RF out 128 IP input over UDP and RTP, GE port, RJ45—ISDBT RF out
Multiplexing	Maximum PID Remapping	255 input per channel
	Function	PID remapping ( automatically or manually)
		Accurate PCR adjusting
		Generate PSI/ SI table automatically

Modulation	ISDB-T	Standard	ARIB STD-B31
		Bandwidth	6M
		Constellation	QPSK, 16QAM, 64QAM
		Guard Interval	1/32, 1/16, 1/8, 1/4
		Transmission Mode	2K, 4K, 8K
		Code rate	1/2, 2/3, 3/4, 5/6, 7/8
		MER	≥40dB
		RF frequency	50~960MHz, 1KHz step
		RF out	6 (or 16) non-adjacent carriers output (maximum bandwidth 192MHz)
		RF output level	-20dBm~+3dBm, 0.1dB stepping
System function	Network management (WEB)
	Chinese and English language
	Ethernet software upgrade
Miscellaneous	Dimension (W×L×H)	482mm×328mm×44mm
	Environment	0~45℃(work)；-20~80℃（Storage）
	Power requirements	AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz

Ordering Information

	IP input	IP output	RF carriers	Scrambling
DVB-C out	128	12	12	N/A
DVB-T out	128	8	8	N/A
ATSC out	128	8	8	N/A
ISDB-T out	V1	128	6	6	N/A
ISDB-T out	V2	128	16	16	N/A

Packing List

HDMI to ISDB-T encoder modulator	1pc
HDMI Cables	8/16/24pcs
Power Cord	1pc

Environment Requirement

Item	Requirement
Machine Hall Space	When user installs machine frame array in one machine hall, the distance between 2 rows of machine frames should be 1.2~1.5m and the distance against wall should be no less than 0.8m.
Machine Hall Floor	Electric Isolation, Dust Free Volume resistivity of ground anti-static material: 1X10⁷~1X10¹⁰W，Grounding current limiting resistance: 1MW (Floor bearing should be greater than 450Kg/㎡)
Environment Temperature	5~40℃(sustainable )，0~45℃(short time)， installing air-conditioning is recommended
Relative Humidity	20%~80% sustainable 10%~90% short time
Pressure	86~105KPa
Door & Window	Installing rubber strip for sealing door-gaps and dual level glasses for window
Wall	It can be covered with wallpaper, or brightness less paint.
Fire Protection	Fire alarm system and extinguisher
Power	Requiring device power, air-conditioning power and lighting power are independent to each other. Device power requires AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz. Please carefully check before running.

FAQ

What are the payment terms that you support?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.

2. What about the lead time?

Usually, if there's stock, we ship the goods within 3~5 working days after the deposit is confirmed. If it is out of stock, the lead time depends.

3. How about the shipping?

When the package is small, we normally choose FedEx, DHL, TNT, and UPS, and so on, while the goods have high weight and volume, we suggest using air or sea shipment.

4. How can I place an order?

(1) Negotiation is agreed upon for the product price and specifications. (2) The Proforma invoice will be sent for confirmation. (3) After the agreement on the proforma invoice, the customer makes the deposit. (4) Manufacturing will be started as soon as the payment is confirmed by our bank. (5) Ship out the goods within the agreed delivery deadline.

5. Can you do OEM for us?

Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you. 6. How about the Warranty? There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
