Multi Channel HDMI Encoder
SFT3228M-N network encoder (Network Encoder Processor) is an encoding device for IP broadcasting. It features 8, 16, or 24 HDMI input channels with MPEG-4 AVC/H.264 video encoding and LC-AAC or HE-AAC audio encoding. Signal sources can include STBs, PCs, and TVs. The device transmits live programs over the Internet or LAN, delivering IP output via UDP (Unicast/Multicast), SRT, RTSP, RTMP, HTTP, and HLS. These output signals can be received by PCs, phones, and other mobile terminals. The SFT3228M-N allows you to access your IP STB, PC, or TV to watch your programs from anywhere.
Send Inquiry
Product Introduction
2 channel HDMI input support H264+H265 encoder (DUP/RTP/RTSP/RTMP/HLS/M3U8/SRT/etc)
4 channel HDMI input support H264+H265 encoder (DUP/RTP/RTSP/RTMP/HLS/M3U8/SRT/etc)
8 channel HDMI input support H
264/MPEG-4/H265 encoder(DUP/RTP/RTSP/RTMP/HLS/M3U8/SRT/etc)
24 channel HDMI input support H264/MPEG-4/H265 encoder(DUP/RTP/RTSP/RTMP/HLS/M3U8/SRT/etc)
Products Description
Engineered for IPTV and digital broadcasting, the SFT3228M-N is a versatile multi-port HDMI encoder supporting flexible scaling from 8 up to 48 inputs. The unit processes professional-grade video in H.265/HEVC or H.264/AVC algorithms, paired with AC3 Pass-through, HE-AAC, LC-AAC, or MPEG-1 Layer 2 audio. For versatile web and network delivery, it outputs concurrent IP streams utilizing protocols like SRT, UDP (Multicast/Unicast), HTTP, RTSP, RTMP, and HLS. This ensures seamless content reception on TVs, computers, setup boxes, and phones worldwide.
Key Features
- Capable of handling up to 24 HDMI inputs (variants available: 2/4/8/16/24 channels), yielding 2/4/8/16/24 SPTS outputs. (Each individual encoder module is restricted to SPTS, with NO MPTS support).
- Video compression standards applied: H.265 and MPEG-4 AVC/H.264.
- Audio encoding provided through LC-AAC, HE-AAC, and MPEG1 Layer II, featuring audio gain modification and AC3 Pass Through.
- IP transmission supported over diverse protocols: UDP (Unicast/Multicast), SRT, RTSP, RTP, RTMP, HTTP, HLS, and M3U8.
- Content overlay options: Integrates LOGOs, QR codes, and text captions (Default languages: English, 中文, العربية, ไทย, हिन्दी, اردو; contact us for additional language options).
- Functionality includes "Null PKT Filter" operations.
- Configuration and firmware upgrades are conveniently handled via web-based management.
Technical specification
