IP input ASI output IPTV Transcoder is a professional bidirectional transcoder to convert video between H.264 and MPEG-2 format and also to transcode between HD and SD programs simultaneously.

Send Inquiry

Product Introduction

IP input ASI output IPTV Transcoder

IP input ASI output IPTV Transcoder is a professional bidirectional transcoder to convert video between H.264 and MPEG-2 format and also to transcode between HD and SD programs simultaneously. It is equipped with 6 Tuner inputs and an IP input to receive digital channels. After transcoding, it outputs MPTS & SPTS through the DATA port or ASI port.

This transcoder supports advanced re-multiplexing and can effectively provide operators with real-time code rate switch and optimize the video with its high performance.

BISS function is now embedded to descramble Tuner and IP input programs and CC function as well to transport your closed caption (or teletext).

It can be easily managed through web NMS system, and has become an ideal solution for operator to provide high quality video trans-coding.

1.2 Key Features of IP input ASI output IPTV Transcoder

Ø Support 8*IP (SPTS/MPTS) input plus 6 DVB-S2/ASTC Tuner input

Ø Support 8*SPTS & 1*MPTS (UDP/RTP/RTSP) output; 1 ASI (MPTS) output

Ø Video Trans-coding: MPEG-2 SD/HD and H.264 SD/HD any-to-any

Ø Audio Trans-coding: LC-AAC, MP2 and AC3 any-to-any or pass-through.

Ø Support maximal 8 SD or 4 HD programs trans-coding

Ø Support maximal 8 channel audio trans-coding

Ø Support HD and SD resolutions

Ø Support CBR and VBR rate control

Ø Support CC (closed caption)

Ø Support BISS descrambling

Ø Support IP out with null packet filtered

Ø Advanced re-multiplexing

Ø LCD & Key board local control; web NMS management

Technical Specifications of IP input ASI output IPTV Transcoder

Stream In	8 MPTS/SPTS over UDP/RTP/RTSP, 1000M Base-T Ethernet Interface/ SFP interface
	6 * (DVB-S/S2/C/T/ISDB-T/ATSC) Tuners; 6 * ASI (optional)
BISS Descramble	Maximum 8 programs
Video	Resolution	1920x1080I,1280x720P, 720x576i, 720x480i 480x576, 544x576, 640x576, 704x576
	Trans-coding	4MPEG2 HD → 4MPEG2/H.264 HD ; 4MPEG2 HD → 4MPEG2/H.264 SD ; 8 MPEG2 SD → 8 MPEG2/H.264 SD
		4* H.264 HD → 4MPEG2/H.264 HD ; 4 H.264 HD → 4MPEG2/H.264 SD ; 8 H.264 SD → 8 *MPEG2/H.264 SD
	Rate Control	CBR/VBR
Audio	Trans-coding	Audio Trans-coding: AAC, MP2 and AC3 any-to-any or pass-through.
	Sampling rate	48KHz
	Bit Rate	32/48/64/96/128/192/224/256/320/384Kbps
Stream Out	8SPTS & 1MPTS over UDP/RTP/RTSP, 1000M Base-T Ethernet Interface (UDP/RTP uni-cast / multicast) /SFP interface
	1*ASI (as a copy of one of the 8 SPTS or the MPTS) output, BNC interface
System Function	LCD & Key board control; web NMS management
	Ethernet software upgrade
General	Dimensions	430mm×405mm×45mm(WxDxH)
	Temperature range	0~45℃(Operation), -20~80℃(Storage)
	Power requirements	AC 110V±10%, 50/60Hz; AC 220V±10%,50/60Hz
