OLT Huawei MA5608T
OLT Huawei MA5608T
Summary
OLT Huawei MA5608T is designed to address Fiber to the premise (FTTP) or deep fiber deployment scenarios where a large OLT chassis may not be the best fit for a variety of reasons. Huawei’s mini OLT MA5608T is designed to be the perfect complement to the other MA5600 series larger OLTs and offers the same carrier grade features and performance.
Highlights Convergence And Access Integration:
• Provides super large convergence switching capacity. Specifically, an MA5600T series device supports 3.2 Tbit/s backplane
capacity, 1,920 Gbit/s switching capacity, and 512,000 MAC addresses.
• Provides super high-density cascading capability. Specifically, an MA5600T series device supports a maximum of 46 x 10GE
or 768 GE services, with no additional convergence switches.
OLT Huawei MA5608T Positioning:
The MA5608T has a strong adaptability to the environment and can be deployed quickly. In FTTx networks, the OLT is moved closer to the user side, which can save backbone optical cable resources. This solves the problem of a few users and long access distance, when FTTx services are applied in an area with a low population density.
Deployed at the remote end, including the base stations (BSs) and outdoor environments
2 U high, and supports a maximum of two service boards
Connected to MxUs or ONTs and used in FTTB/C and FTTH scenarios
Connected to xDSL terminals and phones and used in the MSAN/DSLAM scenario
Dimensions and weight of the MA5608T
| Item | Specification |
| Dimensions (W x D x H, excluding mounting brackets) | 442mm×244.5mm×88.1mm |
| Dimensions (W x D x H, including mounting brackets of IEC standard) | 482.6mm×244.5mm×88.1mm |
| Dimensions (W x D x H, including mounting brackets of ETSI standard) | 535mm×244.5mm×88.1mm |
| Weight (empty chassis) | 3.55kg |
Running environment parameters of the MA5608T
Environment Parameter | Specification |
|---|---|
Working environment temperature | -40°C to +65°C |
Working environment humidity | 5% RH to 95% RH |
Atmosphere pressure | 70 kPa to 106 kPa |
Altitude | < 4000 m |
