5G ONU XPON
5G ONU XPON
ONT-4GE-RFDW is launched to be oriented to multi-service integration network as an optical network unit device, which belongs to XPON HGU terminal for FTTH/O scenario. It configures four 10/100/1000Mbps ports, WiFi (2.4G+5G) port and RF interface that providing with high-speed data services and high-quality video services to users.
5G parameters
Network standard | IEEE 802.11ac |
Antennas | 2T2R, support MU-MIMO |
Maximum supported rates | 20M:173.3Mbps 40M:400Mps 80M:866.7Mbps |
Data modulation type | BPSK QPSK 16QAM 64QAM 256QAM |
Maximum output power | ≤20dBm |
Typical channel (customizable)
| 36,40,44,48,52,56,60,64,100,104, 108,112,116,120 ,124,128,132,136, 140,144,149,153,157,161,165 |
Encryption mode | WPA,WPA2,WPA/WPA2,WEP,NONE |
Encryption type | AES,TKIP |
Interface parameters
PON interface | • ClassB+ • -27dBm receiver sensitivity • Wavelength:upstream 1310nm,downstream 1490nm • Support WBF • Flexible mapping between GEMPort and TCONT • Authenticationmethod:SN/password/LOID(GPON) • Two-way FEC(Forwarderrorcorrection) • Support DBA for SRand NSR |
Ethernet port | • Stripping based on VLAN Tag/Tag for Ethernet port. • 1:1VLAN/N:1VLAN/VLAN Pass-through • QinQVLAN • MACaddress limit • MACaddress learning |
WLAN | • IEEE 802.11b/g/n • 2×2MIMO • Antenna gain:5dBi • WMM(Wi-Fi multimedia) • Multiple SSID multiple • WPS |
RF interface | • Supports standard RF interfaces • Support hd data streaming |
Hardware parameters
Dimension | 220mm x 150mm x 32mm(Without antenna) |
Weight | 310g |
Working environment temperature | 0℃～+40℃ |
Working environment humidity | 5% RH～95% RH, non-condensing |
Power adapter input level | 90V～270V AC，50/60Hz |
Device power supply | 11V～14V DC，1 A |
Static power consumption | 7.5 W |
Maximum power consumption | 18 W |
Interfaces | 1RF+4GE+Wi-Fi(2.4G+5G) |
indicator light | POWER/PON/LOS/LAN/WLAN/RF |
