Product information
The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing,
splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
Send Inquiry
Product Introduction
Product Description
Product information
The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing,
splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
Application
1.Optical Telecommunication System
2.LAN ,Optical fiber Communication System
3.Optical fiber broadband access network
4.FTTH access network
Features
1Total enclosed structure.
2Material: PP+GF ,wet-proof/water-proof/dust-proof/anti-aging, protection level up to IP68.
3Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.
4Cable ,pigtails ,patch cords are running through own path without disturbing each other, cassette type SC adaptor installation, easy maintenance.
5Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.
6Cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.
Specification
|
Item
|
Technical parameters
|
|
Dimension(L×W×H)mm
|
380*230*110MM
|
|
Material
|
Reinforced thermoplastic
|
|
ApplicableEnvironment
|
Indoor/Outdoor
|
|
Installation
|
Wallmounting or Polemounting
|
|
Cable Type
|
Ftthcable
|
|
Input cablediameter
|
2ports for cables from 8 to17.5mm
|
|
Drop cables dimensions
|
Flat cables:8 ports with2.0x3.0mm
|
|
Operating temperature
|
-40 to +65℃
|
|
IPProtectionDegree
|
68
|
|
Adapter type
|
SC&LC
|
|
InsertionLoss
|
≤0.2dB 1310nm &1550nm
|
|
Port of transmission
|
8 fibers
|
