Ku-Band Quattro LNBF
GKF-2704KQ Universal Ku-Band Quattro LNBF
Water-resist, frost-resist, uv-resist
Support HD 1080, 3D, 4K
Ultra-low noise figure
Wideband coverage 950~2150MHz
Send Inquiry
Product Introduction
GKF-2704KQ Universal Ku-Band Quattro LNBF
Features
Water-resist, frost-resist, uv-resist
Support HD 1080, 3D, 4K
Ultra-low noise figure, excellent weak signal reception capability
Wideband coverage, adaptable to multi-scenario signal requirements
High conversion gain, excellent gain flatness, stable and uniform signal amplification
Specifications of Ku-Band LNBF
| ltem | Specification |
| nput Frequency Range | Low Band:10.70~11.70GHz |
| HighBand:11.70~12.75GHz | |
| Ouput Frequency Range | Low Band:950~1950MHz |
| HighBand:1100~2150MHz | |
| LO.Frequency | Low Band:9.75GHz |
| HighBand:10.60GHz | |
| LO.Frequency Stabilty | ±1.0MHz(Max.)@+25℃ |
| ±2.0MHZ(Max.J@-30℃~+70℃ | |
| LO.Phase Noise | -75dBc/Hz@IKHz |
| -80dBc/Hz@10KHz | |
| -90dBc/Hz@100KHz | |
| Conversion Gain | 60dB(Typ.J |
| Noise Figure | 0.6dB(Typ. |
| Gain Flatness | ±0.5dB/27MHz |
| Cross POL.Isolation | 20dB(Min.) |
| Image Rejeclion | 40dB(Min.) |
| Output VSWR | 2.0:1(Typ.) |
| PldB | OdBm(Min. |
| DC Current Consumption | 220mA(Typ.J |
| Low/High Band Switching | Low Band:OHz |
| HighBand:22KHz±4KHz | |
| POL.Switching Voltage | 10.5~14.0V@Vertical |
| 16.0~20.0V@Horizontal | |
| Relafive Humidity | 0%~95% |
| Operating Temperature | 30℃~+70℃ |
| Connector Type | 750 Female Connector |
