1GHz Outdoor Bi-Directional CATV Optic Signal Node
In order to ensure the excellent quality of Outdoor 2 Output Trunk Amplifier, Ftth Mini Node With Filter, Flat Cable Wire, every employee of our company constantly improves their self-cultivation and strives for perfection in every link. We insist on continuous innovation around customer needs, increase investment in basic research, and further consolidate the company's technical capabilities, so as to meet customers' needs for more high-end products, and enhance the company's brand power and core competitiveness. Since the establishment of the enterprise, our mission is to lead the industry's technical concepts and create excellent product quality. We will focus on the five major development concepts of innovation, coordination, green, openness and sharing, and adhere to the direction of market-oriented reform. We actively integrate resources and give full play to our advantages to increase new economic growth points.
Cable TV Optical Node SR-808R is an 8-way reverse path optic receiver. It can recover RF signal from Upstream Optic signal at the headend or remote control center. This device has 8 independence receivers integrated into a 1RU 19”casing to supply service for HFC network terminal. With ultra high receive sensitivity, it can provide to farther place.
Performance charercestics of Cable TV Optical Node
Performance | Index | Supplement | |||||
| Min | Typ. | Max | |||||
| Optical feature | CATV work wavelength | (nm) | 1200 | 1620 | |||
Responsivity | R13 | (A/W) | 0.85 | 0.95 | 1310nm | ||
R15 | 0.85 | 1 | 1550nm | ||||
R16 | 0.85 | 1610nm | |||||
Optical link budget loss | (dB) | 17 | |||||
Receiving power range | Typical | (dBm) | -17 | -7 | |||
Sensitivity | -23 | -22 | Pr | ||||
overload | 0 | 1 | Po | ||||
Number of optical receiver | (pcs) | 8 | |||||
Return loss | (dB) | 50 | |||||
Optical connector | SC/APC | LC/APC optional | |||||
| RF feature | Optical bandwidth | (MHz) | 5 | 200 | |||
RF Output level | (dBμV) | 30 | 60 | ||||
RF gain adjustable | (dB) | -30 | 0 | ||||
Flatness | (dB) | -0.75 | 0.75 | ||||
Return loss | (dB) | 16 | |||||
RF Test Point | (dB) | -20.5 | -20 | -19.5 | |||
Noise power ratio | (dB) | 37 | F-P, link loss >15dB | ||||
41 | FDB, link loss >15dB | ||||||
| General feature | Power supply | AC | (V) | 90 | 220 | 265 | |
DC | -30 | -40 | -72 | ||||
Power Consume | (W) | 96 | |||||
Work temp | (℃) | -40 | 65 | ||||
Work relative humidity | (℃) | 5 | 95 | ||||
Size | (mm) | 19×12×17.5 | (W)×(D)×(H) | ||||
Our goal is to satisfy our customers by offering golden service, good price and 1GHz Outdoor Bi-Directional CATV Optic Signal Node. Excellent talents play their strengths in our company. Through continuous exploration and innovation, we can create high-quality products in the industry with professional attitude and achieve industry leadership with team wisdom. Values are deeply rooted in the enterprise, which is the basic code of conduct for the enterprise to shoulder the mission and achieve the vision.
