1550nm Mini Transmitter
1550 Mini Transmitter
Summary
1550 mini transmitter, which is desighned for FTTH network with 1550nm output optical wavelength. This transmitter has high performance and designed with ultra ow noise technology .
Detail Images for 1550 mini transmitter
Characteristic
1. Designed for FTTH(Fiber To The Home)Networks
2. Excellent Linearity and flatness
3. Single-mode fiber high return loss
4. Using GaAs amplifier active devices
5. Ultra low noise technology
6. Using DFB coaxial small package laser
7. Smaller size and easier install
8. Red-LED for power indication
Parameters of 1550nm mini transmitter
Performance | Index | Supplement | ||
Customer interface | RF Connector | F-Female | ||
| optical connector | SC/APC | |||
| power supply | F-Female | |||
Optic feature | output optical wavelength | nm | 1550 | |
Output optical power | mW | 10 | ||
Optic fiber type | single mode | |||
Return loss | dB | ≥45 | ||
RF feature | Frequency range | MHz | 47-1000 | |
Input level | dBmV | 80±5 | ||
Flatness | dB | ± 0.75 | ||
Return loss | dB | >16 | ||
Input impedance | Ω | 75 | ||
C/N | dB | ≥52 | ||
CTB | dB | ≥63 | ||
| CSO | dB | ≥60 | ||
Other parameter | Size | mm | 100×98×28 | |
Power supply | VDC | 12 | ||
Power Consume | W | ≤2 | ||
Packaging for 1550 mini transmitter
